M24640/21 FXW, FXWA, FXOW

The M24640/21 cable is a lightweight, circuit integrity cable designed for shipboard purposes. It is a watertight and non-flexing cable that comes in three variations: FXWA (armored), FXW (unarmored), and FXOW (shielded). The M24640/21 also has a temperature rating of 150°C and a voltage rating of 600V. Order M24640/21 Mil-Spec Shipboard Cable online today through Allied Wire and Cable.

6 items

  • FXOW-3
    FXOW-3
    FXOW-3
    $0.00 / 500 FT
    • Ampacity (50C): 10
    • Approx LBS/MFT: 116.00
    • AWG Size: 16
    Order
    Add to List
  • FXW-3
    FXW-3
    FXW-3
    $0.00 / 500 FT
    • Ampacity (50C): 10
    • Approx LBS/MFT: 69.00
    • AWG Size: 16
    Order
    Add to List
  • FXWA-3
    FXWA-3
    FXWA-3
    $0.00 /
    • Ampacity (50C): 10
    • Approx LBS/MFT: 0.00
    • Armor Material: Aluminum
    Order
    Add to List
  • FXOW-4
    FXOW-4
    FXOW-4
    $0.00 / 500 FT
    • Ampacity (50C): 17
    • Approx LBS/MFT: 146.00
    • AWG Size: 14
    Order
    Add to List
  • FXW-4
    FXW-4
    FXW-4
    $0.00 / 500 FT
    • Ampacity (50C): 17
    • Approx LBS/MFT: 102.00
    • AWG Size: 14
    Order
    Add to List
  • FXWA-4
    FXWA-4
    FXWA-4
    $0.00 /
    • Ampacity (50C): 17
    • Approx LBS/MFT: 0.00
    • Armor Material: Aluminum
    Order
    Add to List

M24640/21 Mil-Spec Shipboard Cable Specifications

M24640 Construction:

  • Conductor: 4 Bare Copper Conductors
  • Insulation: Mica/Polyimide Tape
  • Jacket: LSZH
  • Wrap: Mica/Polyimide Tape
  • Shield: FXWA and FXOW only - Overall Tinned Copper Braid
  • Armor: FXWA only - Aluminum

M24640/21 Approvals and Ratings:

  • Mil-Spec: MIL-C-24640/21
  • Navy Specs:
    • FXW - Unarmored
    • FXWA - Armored
    • FXOW - Shielded
  • Temperature Rating: 150°C
  • Voltage Rating: 600 volts

M24640/21 Features:

  • Low Smoke Zero Halogen
  • Watertight
  • Non-flexing
