EPDM125-18

EPDM125-18
$0.00 / 1000 FT
EPDM125-18
  • Approx LBS/MFT: 0.00
  • AWG Size: 18
  • Cond. Material: Tinned Copper
  • Conductor Stranding: 16/30
  • CSA Type: AWM
  • Insul. Material: Ethylene Propylene Diene Monomer Rubber (EPDM)
  • Max. Temp: 125C
  • No. of Strands: 16
  • Nom. Insul. Thick. (in): 0.030
  • Nom. O.D. (in): 0.1090
  • Strand Size: 30
  • UL Style: 3484
  • Voltage: 600

EPDM125-18 18 Gauge EPDM (125°) 600 Volts

Our EPDM125-1818 gauge wire is part of our Hook Up Wire / Lead Wire line. EPDM125-18 is an 18 awg wire made of a 16/30 stranded tinned copper conductor with an EPDM insulation and is typically stocked in black. These wires are used as appliance wire and as lead wire for motors, ballasts, transformers, coils or solenoids where high-temperature is required. Rated for 600 volts and up to 150°, these wires are widely used in high-temperature cable.
