3317-10-37T
3317-10-37T
0.00
/
- Approx LBS/MFT: 38.00
- AWG Size: 10
- Cond. Material: Tinned Copper
- Conductor Stranding: 37/.0168
- CSA Type: RR-64
- Insul. Material: XLPVC
- Max. Temp: 105C
- Min. Temp: -55C
- No. of Strands: 37
- Nom. Insul. Thick. (in): 0.016
- Nom. O.D. (in): 0.1490
- Strand Size: 0.0168
- UL Style: 3317
3317-10-37T 10 Gauge UL1430, UL3317, UL1557 Hook Up Wire
Our 3317-10-37T 10 gauge wire is part of our Hook Up Wire / Lead Wire line. 3317-10-37T is a 10 awg wire with a 37/.0168 conductor stranding and an outer diameter of 0.149 and an irradiated PVC insulation that comes in a variety of colors for easy identification. Weighing approximately 38 lbs/MFT, this cable is best used in the internal wiring of electronic equipment, business machines, and appliances. UL1430 is MIL-W-16878/2 approved. For the MIL-W-16878/2 Type C approved cable, the maximum voltage rating is 1000 volts, while the UL/CSA maximum voltage rating is 300 volts. As for temperature range, the Mil-Spec approved cable works best between -55° and +105°, while the UL/CAS maximum temperature is +105°.
