3317-14-19T

3317-14-19T
$0.00 / 1000 FT
  • Approx LBS/MFT: 15.00
  • AWG Size: 14
  • Cond. Material: Tinned Copper
  • Conductor Stranding: 19/.0147
  • CSA Type: RR-64
  • Insul. Material: XLPVC
  • Max. Temp: 105C
  • Min. Temp: -55C
  • No. of Strands: 19
  • Nom. Insul. Thick. (in): 0.016
  • Nom. O.D. (in): 0.1070
  • Strand Size: 0.0147
  • UL Style: 3317
  • Voltage: 300

3317-14-19T 14 Gauge UL1430, UL3317, UL1557 Hook Up Wire

Our 3317-14-19T 14 gauge wire is part of our Hook Up Wire / Lead Wire line. 3317-14-19T is a 14 awg wire with a 19/.0147 conductor stranding and an outer diameter of 0.107 and an irradiated PVC insulation that comes in a variety of colors for easy identification. Weighing approximately 15 lbs/MFT, this cable is best used in the internal wiring of electronic equipment, business machines, and appliances. UL1430 is MIL-W-16878/2 approved. For the MIL-W-16878/2 Type C approved cable, the maximum voltage rating is 1000 volts, while the UL/CSA maximum voltage rating is 300 volts. As for temperature range, the Mil-Spec approved cable works best between -55° and +105°, while the UL/CAS maximum temperature is +105°.
