Our flexible FEP Connection Cables are designed for extreme environments and are suitable for use in engine rooms where high temperatures are a concern. This flexible cable has resistance to oils, fuel, chemicals, and cold and high heat. It also exhibits excellent EMC characteristics (copper braiding should be connected circularly to optimize the EMC characteristics).
16 items
-
187651575$0.00 / 1000 FT
- Approx LBS/MFT: 65.00
- AWG Size: 16
- Cond. Material: Tinned Copper
-
187653575$0.00 / 1000 FT
- Approx LBS/MFT: 122.00
- AWG Size: 16
- Cond. Material: Tinned Copper
Flexible FEP Marine Cable Specifications
FEP Cable Construction:
- Conductor: Stranded Tinned Copper acc. to IEC 60228, EN 60228, VDE 0295, class 5
- Stranding: in layers
- Insulation: Fluorinated Ethylene Propylene (FEP)
- Screen: Tinned Copper Braid
- Inner Jacket: Besilen®
- Jacket: Fluorinated Ethylene Propylene (FEP)
- Jacket Color: Black (RAL 9005)
FEP Cable Ratings and Approvals:
- Nominal Voltage: Uo/U 300/500 V
- Testing Voltage: 2000 V (AC)
- Min. Bending Radius:
- Fixed laying: 5 x O.D.
- Flexible application: 10 x O.D.
- Radiation Resistance: 1 x 107 cJ/kg
- Temperature Range:
- Fixed laying: -55/+180°C
- Flexible application: -55/+180°C
- Halogen-free: not fulfilled
- Absence of Harmful Substances: acc. to RoHS directive of the European Union
- No flame propagation acc. to IEC 60332-3-22 + DIN EN 60332-3-22 cat. A.
- Flame retardant and self-extinguishing acc. to IEC 60332-1-2 + DIN EN 60332-1-2
- Approval: Germanischer Lloyds
