Continental Cordage

AA59569F36T0125

AA59569F36T0125
$297.99 / 1000 FT
AA59569F36T0125
  • Amps: 25
  • Approx LBS/MFT: 13.00
  • Approx. AWG Equivalent: 15
  • AWG Size: 15
  • Collection Name: Flat Braid TPC
  • Cond. Material: ETP Copper, Tinned Copper
  • Construction: 24-5-36
  • Indiv. Ends AWG Size: 36
  • Member AWG: 36
  • Mil-Spec: AA59569A
  • No. of Strands: 24
  • No. of Wires per Strand: 5
  • Nom. Circular Area (Mils): 3000
  • Nom. Flat Width (in): 0.187, 3/16
  • Nom. Thick. (in): 0.020
  • Plating Type: Tin
  • STD QTY: 1000
  • Total No. of Wires: 120

AA59569F36T0125 Flat Braid — Tin Plated Copper

AA59569F36T0125 is a flat braid TPC wire with a wire gauge of 15 AWG and a width of .187" x .020". Constructed from ETP copper with tin plating. Part of the flat braid TPC product family. Perfect for shielding, static discharge, and flexible connections. Bulk orders and cut-to-length options available.
