F Braid 1/32 24 Gauge Mil-Spec AA59569A Flat Braid wire 6 Amp ASTM-B 33 QQB-575 Tin covered Copper Wire point-to-point grounding strap 24 AWG

F BRAID 1/32
$0.00 / 1000 FT
  • Amps: 6
  • Approx LBS/MFT: 4.00
  • AWG Size: 24
  • Cond. Material: Tinned Copper
  • Construction: 16-1-36
  • Nom. Circular Area (Mils): 400
  • Nom. Flat Width (in): 1/32
  • Nom. Thick. (in): 0.020

F Braid 1/32 Flat Braided 24 Gauge Wire - Mil-Spec AA59569

Our F Braid 1/32 flat braid is part of our Mil-Spec Wire and Cable line. F Braid 1/32 is a 24 gauge wire with a tinned copper conductor and a 16-1-36 construction. These cables are rated for an amperage of 6 amps and weighs approximately 4 LBS/MFT. The tinned copper strands in this wire are tightly woven and rolled flat at the time of manufacture and are generally used in battery grounding, bonding straps (in aircraft, watercraft, rail, and vehicles), and as mechanical connections on moving parts.
