LSDHOF-23 — M24643/3 Mil-Spec Shipboard Cable
Our LSDHOF-23 cable is part of our line of Mil-Spec Shipboard Cable. This 7 AWG cable features two stranded bare copper conductors, EPR insulation, and a halogen-free XLPO jacket. It is oil-resistant and has a voltage rating of 600V. This cable is suitable for use in non-watertight, flexing shipboard power and lighting applications.
LSDHOF-23
Part Number
LSDHOF-23
Attributes
No. of Cond.
2
Ampacity (50C)
72
Approx LBS/MFT
0.00
AWG Size
7
Cond. Material
Bare Copper
Conductor Stranding
210/30
Insul. Material
Ethylene Propylene Rubber (EPR)
Jacket Material
Halogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)
0.860
Metal Tubes
G
Mil-Spec
M24643/3
No. of Strands
210
Nylon Tubes
5B
Strand Size
30
