1SWF-2 22 Gauge -Mil-C-915/47 Shielded Shipboard Cable
Our 1SWF-2 22 AWG cable is part of our extensive Mil-Spec Wire and Cable line. The 1SWF-2 cable's construction consists of bare copper conductors, PE insulation, and a Neoprene jacket. It also features an overall braided bare copper shield. This cable has a voltage rating of 300V and is watertight. This cable meets both military and navy standards.
1SWF-2
Part Number
1SWF-2
Attributes
No. of Cond.
2
Approx LBS/MFT
0.00
AWG Size
22
Cond. Material
Bare Copper
Insul. Material
Polyethylene (PE)
Jacket Material
Neoprene
Max O.D. (in)
0.625
Metal Tubes
C
Mil-Spec
M915E/47
Nylon Tubes
4E
Shield
Overall Braid Shield
Shield Material
Bare Copper Braid
Voltage
300
