1084A - Power Limited Tray Cable (20 AWG, 8-Triad, 300V)

Belden 1084A is a power limited tray cable designed for industrial instrumentation and control applications.

This cable contains 8 triads of 20 AWG, 7-strand bare copper conductors with individually foil shielded pairs and an overall Beldfoil shield. Rated for 300V, the cable uses Polyvinylchloride (PVC) insulation and a Polyvinylchloride (PVC) jacket, with 0.064-inch jacket thickness and nominal outside diameter of 0.575 inches. The cable is approved to NEC Type PLTC/ITC/CMG and CSA Type CMG FT4 standards. Approximate weight is 234 lbs/MFT with E1 color coding.

To explore additional configurations and related part numbers, browse the full Belden cable product line.

Contact Allied Wire & Cable for pricing, availability, and technical support.

Frequently Asked Questions

What is the conductor configuration of Belden 1084A?

Belden 1084A features 8 triads of 20 AWG conductors.

What is the voltage rating of Belden 1084A?

This cable is rated for 300 volts.

What shielding does Belden 1084A use?

Belden 1084A has individual foil shields on each pair plus an overall Beldfoil shield.

What NEC type is Belden 1084A?

Belden 1084A is rated NEC Type PLTC/ITC/CMG.
