1536-12-19T

1536-12-19T
$0.00 / 100 FT
  • Approx LBS/MFT: 23.00
  • AWG Size: 12
  • Cond. Material: Tinned Copper
  • Conductor Stranding: 19/.0185
  • CSA Type: AWM
  • Insul. Material: XLPVC
  • Max. Temp: 80C
  • Min. Temp: -55C
  • No. of Strands: 19
  • Nom. Insul. Thick. (in): 0.01
  • Nom. O.D. (in): 0.1140
  • Strand Size: 0.0185
  • UL Style: 1536
  • Voltage: 150

1536-12-19T 12 Gauge UL1429, UL1534, UL1536 Hook Up Wire

Our 1536-12-19T 12 gauge wire is part of our Hook Up Wire / Lead Wire line. 1536-12-19T is a 12 awg wire with a 19/.0185 conductor stranding and an outside diameter of 0.114. It's PVC insulation comes in a variety of colors allowing for easy identification when multiple colors are used. Some of these wires are MIL-W-16878/1 approved and weigh approximately 23 lbs/MFT. Those that are MIL-W-16878/1 approved have a temperature range of -55° to +105° and a maximum voltage of 600 volts while those that do not have a maximum temperature of 80° and a voltage rating of 150 volts. These wires are used for the internal wiring of electronic equipment, computers, business machines, and appliances.
