2XOW-18 26 AWG MIL-C-24640/12 Cable
Our 2XOW-18 cable is part of our Marine Wire, Boat Cable & Shipboard Cable line of Wire & Cable. 2XOW-18 is composed of a 7/35 stranded tinned copper conductor with cross-linked polyalkene insulation, a cross-linked polyolefin (XLPO) jacket, and an overall shield of tinned copper braid. These cables are rated for a voltage of 600 volts and have a temperature rating of 105°. 2XOW cable is unarmored and shielded and can be used for electrical, communication, and instrumentation purposes. It is non-watertight, non-flexing cable.
2XOW-18
Part Number
2XOW-18
Attributes
Approx LBS/MFT
201.00
AWG Size
26
Cond. Material
Tinned Copper
Conductor Stranding
19/38
Insul. Material
Cross-Linked Polyalkene
Jacket Material
Halogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp
135C
Metal Tubes
B
Mil-Spec
M24640/17
No. of Pairs
18
No. of Strands
19
Nom. O.D. of Cable (in)
0.504
Nylon Tubes
4B
Shield
Overall Braid Shield
Shield Material
Tinned Copper Braid
Strand Size
38
Voltage
600
