2XSOW-14 22 Gauge MIL-C-24640/9 Cable
Our 2XSOW-14 22 gauge cable is part of our Marine Wire, Boat Cable and Shipboard Cable line of Wire and Cable. 2XSOW-14 is composed of a 7/30 stranded tinned copper conductor with cross-linked polyalkene insulation and a cross-linked polyolefin (XLPO) jacket. These cables are rated for a voltage of 600 volts and have a maximum temperature of 105 °C. 2XSOW cables are lightweight, unarmored, watertight, and non-flexing.
2XSOW-14
Part Number
2XSOW-14
Attributes
Approx LBS/MFT
460.00
AWG Size
22
Cond. Material
Tinned Copper
Conductor Stranding
7/30
Insul. Material
Cross-Linked Polyalkene
Jacket Material
Cross-Linked Polyolefin (XLPO)
Max. Temp
105 C
Mil-Spec
M24640/9
No. of Pairs
14
No. of Strands
7
Nom. O.D. of Cable (in)
0.720
Strand Size
30
