2XSXOW-4

2XSXOW-4
$0.00 / 100 FT
  • Approx LBS/MFT: 147.00
  • AWG Size: 26
  • Cond. Material: Tinned Copper
  • Conductor Stranding: 7/34
  • Insul. Material: Cross-Linked Polyalkene
  • Jacket Material: Cross-Linked Polyolefin (XLPO)
  • Max. Temp: 105 C
  • Mil-Spec: M24640/13
  • No. of Pairs: 4
  • No. of Strands: 7
  • Nom. O.D. of Cable (in): 0.390
  • Strand Size: 34

2XSXOW-4 26 Gauge MIL-C-24640/13 Cable

Our 2XSXOW-4 26 gauge cable is part of our Marine Wire, Boat Cable and Shipboard Cable line of Wire and Cable. 2XSXOW-4 is composed of a 7/34 stranded tinned copper conductor with cross-linked polyalkene insulation, a cross-linked polyolefin (XLPO) jacket, and individually braid shielded pairs with overall braid shield of tinned copper. These cables are rated for a voltage of 600 volts and have a maximum temperature of 105 °C. This type of cable is non-watertight and non-flexing.
