COM 36040 - 22 AWG Hub-LINK™ LSZH Transit Cable
The COM 36040 communication cable is part of our Category Computer Cable line. This 22 AWG cable features 100 twisted pairs of solid bare copper conductors, LSZH Polyolefin (PO) insulation, and a LSZH Polyolefin (PO) jacket. It also has an overall copper tape wrap shield. This cable is UL Listed for Type CMR-LS, CMG-LS, and CM-LS.
COM 36040
Part Number
COM 36040
Attributes
Approx LBS/MFT
695
AWG Size
22
Cond. Material
Bare Copper
Conductor Stranding
solid
CSA Type
C22.2 No. 218-08
Insul. Material
Low Smoke Zero Halogen (LSZH) Polyolefin (PO)
Jacket Material
Low Smoke Zero Halogen (LSZH) Polyolefin (PO)
Max O.D. (in)
1.32
No. of Pairs
100
No. of Strands
1
Shield
Overall Tape Shield
Shield Material
Copper Tape
UL Style
CMR-LS, CMG-LS, CM-LS
