$0.00 / 1000 FT
  • Approx LBS/MFT: 0.00
  • AWG Size: 6
  • Cond. Material: Tinned Copper
  • Conductor Stranding: 84/25
  • Insul. Material: Ethylene Propylene Diene Monomer Rubber (EPDM)
  • Max. Temp: 150C
  • No. of Strands: 84
  • Nom. Insul. Thick. (in): 0.125
  • Nom. O.D. (in): 0.4650
  • Strand Size: 25
  • UL Style: 3499

EPDM7.5-6 6 Gauge EPDM Cable (150°) 7500 Volts

Our EPDM7.5-6 6 gauge wire is part of our Hook Up Wire / Lead Wire line. EPDM7.5-6 is a 6 awg wire made of an 84/25 stranded tinned copper conductor with an EPDM insulation that is stocked in black. EPDM Cable may be used in many high voltage applications and as appliance wire, lead wire for motors, transformers, and coils where high temperature is required. It offers good dielectric strength, excellent abrasion resistance, low-temperature flexibility, and stripping ability.
