LS6SGA-200 4/0 Gauge MIL-C-24643/19 (LS6SJU, LS6SJA) Cable
Our LS6SGA-200 4/0 gauge cable is part of our Mil-Spec Wire and Cable line of Wire and Cable.LS6SGA-200 is composed of a bare copper conductor with silicone rubber glass tape insulation and a halogen-free (LSZH) cross-linked polyolefin (XLPO) jacket. These cables are rated for a voltage of 1000 volts and an ampacity of 202 at 50°. LS6SJU cable is aluminum braid armored, non-flexing, and watertight with surface markings.
LS6SGA-200
Part Number
LS6SGA-200
Attributes
No. of Cond.
6
Ampacity (50C)
202
Approx LBS/MFT
0.00
Armor Material
Aluminum Braid
AWG Size
4/0
Cond. Material
Bare Copper
Insul. Material
Silicone Rubber Glass Tape
Jacket Material
Halogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max O.D. (in)
2.250
Metal Tubes
W
Mil-Spec
M24643/19
Nylon Tubes
9B1
