Additional Ratings:
UL 1441; UL VW-1; NEMA VS-1; MIL-I-3190E
-
Approx LBS/MFT:
2.3
-
Color:
Natural
-
Expanded I.D. (in):
0.113"
-
Material:
Fiberglass Braid coated with Silicone Rubber
-
Max. Temp:
200C
-
Min. Temp:
-70C
-
Nom. I.D. (in):
0.053"
-
Quantity:
1000 FT
PF20016 NA001 — Alpha Fiberglass Braided Sleeving
Alpha PF20016 NA001 is a high-performance fiberglass braid tubing coated with silicone rubber, designed to withstand extreme temperatures from -70°C to 200°C. Featuring an expanded inner diameter of 0.113 inches and a nominal inner diameter of 0.053 inches, this lightweight tubing weighs approximately 2.3 lbs per thousand feet. It meets rigorous standards, including UL 1441, UL VW-1, NEMA VS-1, and MIL-I-3190E, ensuring superior reliability and safety. Perfect for applications requiring high-temperature resistance, Alpha PF20016 NA001 is ideal for electrical insulation, fluid transfer, and protective covering in demanding industries such as aerospace and automotive.
