Additional Ratings:
UL 1441; UL VW-1; NEMA VS-1; MIL-I-3190E
-
Approx LBS/MFT:
1.9
-
Color:
Natural
-
Expanded I.D. (in):
0.107"
-
Material:
Fiberglass Braid coated with Silicone Rubber
-
Max. Temp:
200C
-
Min. Temp:
-70C
-
Nom. I.D. (in):
0.047"
-
Quantity:
1000 FT
PF20017 NA001 — Alpha Fiberglass Braided Sleeving
Alpha PF20017 NA001 is a high-performance silicone rubber-coated fiberglass braid designed for a wide range of applications. This versatile product can withstand extreme temperatures, with a minimum temperature rating of -70°C and a maximum temperature rating of 200°C, making it ideal for both high and low-temperature environments. The expanded inner diameter measures 0.107 inches, while the nominal inner diameter is 0.047 inches, providing flexibility and adaptability for various uses. Weighing approximately 1.9 lbs per 1000 feet, this material is lightweight yet durable. Alpha PF20017 NA001 also meets stringent safety and performance standards, including UL 1441, UL VW-1, NEMA VS-1, and MIL-I-3190E, ensuring reliability in critical applications such as electrical insulation, automotive, and aerospace industries.
