Additional Ratings:
UL 1441; UL VW-1; NEMA VS-1; MIL-I-3190E
-
Approx LBS/MFT:
1.1
-
Color:
Natural
-
Expanded I.D. (in):
0.087"
-
Material:
Fiberglass Braid coated with Silicone Rubber
-
Max. Temp:
200C
-
Min. Temp:
-70C
-
Nom. I.D. (in):
0.027"
-
Quantity:
500 FT
PF20022 NA002 — Alpha Fiberglass Braided Sleeving
Alpha PF20022 NA002 is a high-performance silicone rubber-coated fiberglass braid designed for extreme temperature applications. This versatile product operates efficiently in a temperature range from -70°C to 200°C, making it ideal for a variety of demanding environments. With an expanded inner diameter of 0.087 inches and a nominal inner diameter of 0.027 inches, it provides excellent flexibility and durability. Weighing approximately 1.1 lbs per linear foot, Alpha PF20022 NA002 is not only lightweight but also meets stringent industry standards, including UL 1441, UL VW-1, NEMA VS-1, and MIL-I-3190E. This makes it suitable for applications in aerospace, automotive, and industrial sectors where reliability and performance are critical.
