Approx LBS/MFT29
AWG Size23
Cond. MaterialBare Compacted Copper
Conductor Stranding7/32
Dielectric (in)0.146
Dielectric MaterialPolyethylene (PE)
Jacket MaterialPolyethylene (PE)
Max. Temp80C
RG 59U
7 items
Approx LBS/MFT29
AWG Size23
Cond. MaterialBare Copper
Conductor Strandingsolid
Dielectric (in)0.146
Dielectric MaterialPolyethylene (PE)
Jacket MaterialPolyethylene (PE)
Max. Temp80C
Approx LBS/MFT35
AWG Size23
Cond. MaterialBare Copper
Conductor Strandingsolid
Dielectric (in)0.146
Dielectric MaterialFlame-Retardant Semi-Foam Polyethylene (PE)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp75C
Approx LBS/MFT29
AWG Size20
Cond. MaterialBare Copper
Conductor Strandingsolid
Dielectric (in)0.133
Dielectric MaterialFoam Fluorinated Ethylene Propylene (FFEP)
Jacket MaterialFlamarrest
Max. Temp75C
Approx LBS/MFT86
AWG Size20
Cond. MaterialBare Copper
Conductor Strandingsolid
Dielectric (in)0.185
Dielectric MaterialFluorinated Ethylene Propylene (FEP)
Jacket MaterialPolyvinylidene Fluoride (PVDF)
Max. Temp150C
Approx LBS/MFT73
AWG Size20
Cond. MaterialBare Copper
Conductor Strandingsolid
Dielectric (in)0.2
Dielectric MaterialPolyethylene (PE)
Jacket MaterialPolyethylene (PE)
Max. Temp80C
Approx LBS/MFT76
AWG Size20
Cond. MaterialBare Copper
Conductor Strandingsolid
Dielectric (in)0.198
Dielectric MaterialPolyethylene (PE)
Jacket MaterialPolyvinylchloride (PVC)
Max. Temp60C
Belden RG59U Precision Video Cable Specifications
RG 59U Precision Video Cable Ratings and Approvals:
- Flame-Retardant Cable:
- Meets UL AWM Style 1354: 30V, 75°C or 30V, 80°C
- NEC Type CMR
- CEC Type CMG FT4
- Maximum Temperature Rating: 60°C, 75°C, 80°C, or 150°C (see part info)
RG 59U Precision Video Cable Construction:
- Conductor: Bare Copper
- Insulation:
- Non-Plenum: Polyethylene, Flame-Retardant Semi-Foam Polyethylene, or Gas-Injected Foam High-Density Polyethylene (HDPE)
- Plenum: FEP or Foam FEP
- Jacket:
- Non-Plenum: Polyethylene or PVC
- Plenum: Fluorocopolymer or Flamarrest
- Shield: varies, see part info
