CMR Cable, CMG FT4: Multi-Conductor, Unshielded

Belden NEC Type CMR alarm cables and security cables are ideal for a large variety of applications, including security, intercom/pa systems, sound/audio systems, commercial use, single line telephones, monitor/detection, addressable fire systems, and power-limited controls. Belden's CMR cable is also suitable for control, data, initiating, and notification circuits.

42 items

Belden Cable
5520UE
Approx LBS/MFT8
AWG Size22
Color Code ChartBlack, Red
Cond. MaterialBare Copper
Conductor Strandingsolid
Insul. MaterialPolypropylene (PP)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.017
Requires Quote per FT
Belden Cable
5522UE
Approx LBS/MFT14
AWG Size22
Color Code ChartBlack, Red, White, Green
Cond. MaterialBare Copper
Conductor Strandingsolid
Insul. MaterialPolypropylene (PP)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.017
Requires Quote
Belden Cable
5524UE
Approx LBS/MFT21
AWG Size22
Color Code ChartBlack, Red, White, Green, Brown, Blue
Cond. MaterialBare Copper
Conductor Strandingsolid
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.015
Requires Quote
Belden Cable
5526UE
Approx LBS/MFT27
AWG Size22
Color Code ChartBlack, Red, White, Green, Brown, Blue, Orange, Yellow
Cond. MaterialBare Copper
Conductor Strandingsolid
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.015
Requires Quote
Belden Cable
5529UE
Approx LBS/MFT38
AWG Size22
Color Code ChartBlack, Red, White, Green, Brown, Blue, Orange, Yellow, Purple, Grey, Pink, Tan
Cond. MaterialBare Copper
Conductor Strandingsolid
Insul. MaterialPolyvinylchloride (PVC)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.015
Requires Quote
Belden Cable
5582UE
Approx LBS/MFT14
AWG Size22
Color Code ChartBlack, Red, Yellow, Green
Cond. MaterialBare Copper
Conductor Strandingsolid
Insul. MaterialPolypropylene (PP)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.017
Requires Quote per FT
Belden Cable
5400UE
Approx LBS/MFT12.00
AWG Size20
Color Code ChartBlack, Red
Cond. MaterialBare Copper
Conductor Stranding7/28
Insul. MaterialPolypropylene (PP)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.017
Requires Quote per FT
Belden Cable
5401UE
Approx LBS/MFT16.00
AWG Size20
Color Code ChartBlack, Red, White
Cond. MaterialBare Copper
Conductor Stranding7/28
Insul. MaterialPolypropylene (PP)
Jacket MaterialPolyvinylchloride (PVC)
Jacket Thickness0.017
Requires Quote per FT

Belden Multi-Conductor Unshielded NEC Type CMR Alarm and Security Cable (UL NEC Type CMR, C(UL) CEC Type CMG) Specifications

Belden NEC Type CMR Cable Construction:

  • Conductor: Solid or Stranded Bare Copper
  • Insulation: Polypropylene (PP), Polyolefin (PO), or Polyvinylchloride (PVC) (see part specs for more info)
  • Jacket: Polyvinylchloride (PVC)
  • Jacket Color: Gray
  • RipCord
  • Sequential Footage Markings Every 2 ft.

Belden NEC Type CMR Cable Ratings and Approvals:

  • UL NEC Type CMR
  • NEC Article 800
  • C(UL) CEC Type CMG
  • Flame Tests: UL 1666 Vertical Shaft, C(UL) FT4
  • Voltage Rating: 300V
  • Temperature Rating: 75°C
