Nylon Wrap

Nylon spiral wrap is engineered for high-performance cable management, offering superior abrasion resistance and flexibility. With a rising demand for reliable wire bundling solutions, nylon wrap stands out due to its self-extinguishing properties and robust construction.

Performance data shows that keywords like 'spiral wrap' and 'nylon wrap' attract significant search volume, reflecting the growing need for dependable cable protection in industrial, commercial, and electrical applications. This product is designed to meet stringent safety and compliance standards, ensuring long-lasting performance in demanding environments.

31 items

MM Newman
HT 1 N-100
Abrasion Resistance6.8
Approx LBS/MFT49
ColorNatural
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)100
MaterialNylon
Max. Bundle Dia. (in)7
Requires Quote
MM Newman
HT 1 N-B-100
Abrasion Resistance6.8
Approx LBS/MFT49
ColorBlack
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)100
MaterialNylon
Max. Bundle Dia. (in)7
Requires Quote
MM Newman
HT 1/2 N-100
Abrasion Resistance6.8
Approx LBS/MFT25
ColorNatural
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)100
MaterialNylon
Max. Bundle Dia. (in)4
Requires Quote
MM Newman
HT 1/2 N-500
Abrasion Resistance6.8
Approx LBS/MFT25
ColorNatural
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)500
MaterialNylon
Max. Bundle Dia. (in)4
Requires Quote
MM Newman
HT 1/2 N-B-100
Abrasion Resistance6.8
Approx LBS/MFT25
ColorBlack
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)100
MaterialNylon
Max. Bundle Dia. (in)4
Requires Quote
MM Newman
HT 1/2 N-B-500
Abrasion Resistance6.8
Approx LBS/MFT25
ColorBlack
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)500
MaterialNylon
Max. Bundle Dia. (in)4
Requires Quote
MM Newman
HT 1/4 N-100
Abrasion Resistance6.8
Approx LBS/MFT9
ColorNatural
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)100
MaterialNylon
Max. Bundle Dia. (in)2
Requires Quote
MM Newman
HT 1/4 N-500
Abrasion Resistance6.8
Approx LBS/MFT9
ColorNatural
Dielectric (in)4
Flame RatingSelf-Extinguishing
Length (ft)500
MaterialNylon
Max. Bundle Dia. (in)2
Requires Quote

What is Nylon Spiral Wrap?

Nylon spiral wrap is a flexible, abrasion-resistant tubing designed to organize, protect, and bundle wires, cables, and hoses. Its spiral construction allows for easy installation and removal, making it ideal for dynamic or frequently modified cable assemblies.

Applications

  • Industrial automation and robotics
  • Electrical panel wiring
  • Automotive harness protection
  • Telecommunications and data centers
  • General cable management in harsh environments

Construction

  • Material: High-strength nylon
  • Colors: Black, Natural
  • Lengths: 100 ft, 200 ft, 250 ft, 500 ft
  • Bundle Diameters: 0.5 in to 7 in
  • Nominal I.D.: 0.095 in to 0.93 in
  • Wall Thickness: 0.015 in to 0.035 in

Specifications

  • Temperature Rating: -40°F to 250°F (-40°C to 121°C)
  • Flame Rating: Self-extinguishing
  • Dielectric Strength: 4 (per ASTM D-150)
  • Max. Tensile Strength: 12,000 psi
  • Abrasion Resistance: 6.8 (per ASTM D-1044)
  • Water Absorption: 1.5%
  • Specific Gravity: 1.14
  • Compliance: RoHS, ASTM D-1044, ASTM D-792-66, ASTM D-638-52T, ASTM D-570, ASTM D-150

Additional Information

Nylon spiral wrap is engineered for environments where durability, flexibility, and flame resistance are critical. Its self-extinguishing properties and compliance with industry standards make it a trusted choice for professionals seeking reliable cable protection. Available in multiple sizes and colors to suit a variety of applications.
