Approx LBS/MFT15.50
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding16/30
CSA TypeCL1053
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands16
UL 3191
UL 3191
UL 3191 wire is a Hypalon hook-up wire suitable for use as the internal wiring of appliances. This wire has a maximum temperature of 105°C, a voltage rating of 600VAC, and also features oil resistance. It has Chlorosulphonated Polyethylene insulation with excellent heat resistance, color stability, and electrical properties. UL 3191 wire is recommended for use as motor leads in Class 130(B) insulation systems.
15 items
Approx LBS/MFT20.00
AWG Size16
Cond. MaterialTinned Copper
Conductor Stranding26/30
CSA TypeCL1053
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands26
Approx LBS/MFT26.00
AWG Size14
Cond. MaterialTinned Copper
Conductor Stranding41/30
CSA TypeCL1053
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands41
Approx LBS/MFT37.50
AWG Size12
Cond. MaterialTinned Copper
Conductor Stranding65/30
CSA TypeCL1053
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands65
Approx LBS/MFT55.00
AWG Size10
Cond. MaterialTinned Copper
Conductor Stranding65/28
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands65
Approx LBS/MFT87.50
AWG Size8
Cond. MaterialTinned Copper
Conductor Stranding84/27
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands84
Approx LBS/MFT130.00
AWG Size6
Cond. MaterialTinned Copper
Conductor Stranding84/25
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands84
Approx LBS/MFT185.00
AWG Size4
Cond. MaterialTinned Copper
Conductor Stranding105/24
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands105
UL 3191 Wire Specifications
UL 3191 Wire Construction:
- Conductor: Stranded Tinned Copper
- Separator
- Insulation: Hypalon (Chlorosulfinated polyethylene)
UL 3191 Wire Approvals:
- UL Rating: UL 3191
- CSA Approval: CSA Type CL 1053
- Voltage Rating: 600V
- Temperature Rating: 105°C
