Approx LBS/MFT218.00
AWG Size3
Cond. MaterialTinned Copper
Conductor Stranding133/24
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands133
UL 3191
UL 3191
UL 3191 wire is a Hypalon hook-up wire suitable for use as the internal wiring of appliances. This wire has a maximum temperature of 105°C, a voltage rating of 600VAC, and also features oil resistance. It has Chlorosulphonated Polyethylene insulation with excellent heat resistance, color stability, and electrical properties. UL 3191 wire is recommended for use as motor leads in Class 130(B) insulation systems.
15 items
Approx LBS/MFT280.00
AWG Size2
Cond. MaterialTinned Copper
Conductor Stranding163/24
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands163
Approx LBS/MFT355.00
AWG Size1
Cond. MaterialTinned Copper
Conductor Stranding210/24
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands210
Approx LBS/MFT435.00
AWG Size1/0
Cond. MaterialTinned Copper
Conductor Stranding262/24
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands262
Approx LBS/MFT530.00
AWG Size2/0
Cond. MaterialTinned Copper
Conductor Stranding504/26
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands504
Additional RatingsASTM B-3, B-8, B-33 and B-172
Approx LBS/MFT669.00
AWG Size3/0
Cond. MaterialTinned Copper
Conductor Stranding259/22
CSA TypeCL 1052 CL 1053
Insul. MaterialHypalon (CPSE)
Max. Temp105C
Approx LBS/MFT850.00
AWG Size4/0
Cond. MaterialTinned Copper
Conductor Stranding805/26
CSA TypeCL1052
Insul. MaterialHypalon (CSPE)
Max. Temp105C
No. of Strands805
UL 3191 Wire Specifications
UL 3191 Wire Construction:
- Conductor: Stranded Tinned Copper
- Separator
- Insulation: Hypalon (Chlorosulfinated polyethylene)
UL 3191 Wire Approvals:
- UL Rating: UL 3191
- CSA Approval: CSA Type CL 1053
- Voltage Rating: 600V
- Temperature Rating: 105°C
