Approx LBS/MFT22
AWG Size14
Cond. MaterialSilver Coated Copper
Conductor Stranding19/27
Insul. MaterialSilicone
Max O.D. (in).171, 0.171
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
M16878/8 - Type FF
M16878/8 — Type FF
Our M16878/8 hook-up wire is designed to be flame-retardant and meets Navy smoke, toxicity, and acid gas regulations. This wire is constructed of a stranded silver-plated copper conductor and extruded silicone insulation. It has a maximum temperature of 200°C and is rated at 1000V. The M16878/7 wire is designed for use in applications requiring high flexibility, durability, and high-temperature resistance.
23 items
Approx LBS/MFT22
AWG Size14
Cond. MaterialSilver Coated Copper
Conductor Stranding41/30
Insul. MaterialSilicone
Max O.D. (in).171, 0.171
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
Approx LBS/MFT31
AWG Size12
Cond. MaterialSilver Coated Copper
Conductor Stranding19/25
Insul. MaterialSilicone
Max O.D. (in).190, 0.19
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
Approx LBS/MFT31
AWG Size12
Cond. MaterialSilver Coated Copper
Conductor Stranding65/30
Insul. MaterialSilicone
Max O.D. (in).190, 0.19
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
Approx LBS/MFT44
AWG Size10
Cond. MaterialSilver Coated Copper
Conductor Stranding37/26
Insul. MaterialSilicone
Max O.D. (in).210, 0.21
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
Approx LBS/MFT44
AWG Size10
Cond. MaterialSilver Coated Copper
Conductor Stranding105/30
Insul. MaterialSilicone
Max O.D. (in).210, 0.21
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
Approx LBS/MFT79
AWG Size8
Cond. MaterialSilver Coated Copper
Conductor Stranding133/29
Insul. MaterialSilicone
Max O.D. (in).307, 0.307
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
Approx LBS/MFT114
AWG Size6
Cond. MaterialSilver Coated Copper
Conductor Stranding133/27
Insul. MaterialSilicone
Max O.D. (in).351, 0.351
Max. Temp200C
Mil-SpecM16878/8, MIL-W-16878/8
