M24640/25 9XS

M24640/25 9XS Cable

The M24640/25 cable is a lightweight, circuit integrity cable designed for shipboard purposes. This cable only comes in one variation: 9XS, which is unarmored and low-smoke, zero-halogen. This cable has a temperature range of -20°C to +105°C and is rated at 600V.

3 items

9XS-12
Approx LBS/MFT21.7
AWG Size12
Cond. MaterialTinned Copper
Conductor Stranding37/28
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyolefin (XLPO)
Jacket Thickness0.050
Max. Temp105 C
Requires Quote per FT
9XS-10
Approx LBS/MFT35.7
AWG Size10
Cond. MaterialTinned Copper
Conductor Stranding37/26
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Jacket Thickness0.050
Max. Temp105 C
Requires Quote per FT
9XS-8
Approx LBS/MFT62.8
AWG Size8
Cond. MaterialTinned Copper
Conductor Stranding133/29
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Jacket Thickness0.050
Max. Temp105 C
Requires Quote per FT

M24640/25 9XS Shipboard Cable Specifications

M24640/25 Construction:

  • Component Wires:
    • 4 twisted pairs plus one single conductor
    • 9XS-12 component wires are SAE AS81044/12
    • 9XS-10 and 9XS-8 component wires are SAE AS81044/9
  • Insulation: Cross-linked Polyalkylene
  • Jacket: Low Smoke Cross-linked Polyolefin

M24640/25 Ratings and Approvals:

  • Temperature Rating: -20°C to +105°C
  • Voltage Rating: 600 volts
  • Mil-Spec: MIL-DTL-24640/25
  • Navy Spec: 9XS Cable is unarmored M24640/25 cable
