M24640/26 5XO

M24640/26 5XO Cable

The M24640/26 cable is a lightweight, circuit integrity cable designed for shipboard purposes. This cable only comes in one variation: 5XO, which is unarmored, shielded, and low-smoke, zero-halogen. This cable has a temperature range of -20°C to +105°C and is rated at 600V.

3 items

5XO-3
Approx LBS/MFT8.9
AWG Size16
Cond. MaterialTinned Copper
Conductor Stranding19/29
Insul. MaterialPolyvinylidene Fluoride (PVDF)
Jacket MaterialCross-Linked Polyolefin (XLPO)
Jacket Thickness0.035
Mil-SpecM24640/26
Requires Quote per FT
5XO-4
Approx LBS/MFT13.9
AWG Size14
Cond. MaterialTinned Copper
Conductor Stranding19/27
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyolefin (XLPO)
Jacket Thickness0.035
Mil-SpecM24640/26
Requires Quote per FT
5XO-6
Approx LBS/MFT0
AWG Size12
Cond. MaterialTinned Copper
Conductor Stranding37/28
Insul. MaterialPolyvinylidene Fluoride (PVDF)
Jacket MaterialCross-Linked Polyolefin (XLPO)
Jacket Thickness0.035
Mil-SpecM24640/26
Requires Quote per FT

M24640/26 5XO Shipboard Cable Specifications

M24640/26 Construction:

  • Conductor: Tinned Copper Conductor
  • Component wires are SAE-AS81044/12
  • Shield: Overall Braid Shield, 90% shield coverage, tinned copper shield material
  • Jacket: Low Smoke Cross-linked Polyolefin

M24640/26 Ratings and Approvals:

  • Temperature Rating: -20°C to +105°C
  • Voltage Rating: 600 volts
  • Mil Spec: MIL-DTL-24640/26
  • Navy Specs:
    • 5XO cable is shielded and unarmored
