M24640/6 2XAO, 2XAOW

M24640/6 2XAO, 2XAOW Cable

The M24640/6 is a lightweight, non-flexing shipboard cable. This Mil-Spec cable comes in two variations: 2XOAW (watertight) and 2XAO (non-watertight). Both variations of the M24640/6 cable are shielded. This specialty shipboard cable has a voltage rating of 600 volts.

10 items

2XAO-10
Approx LBS/MFT200.00
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding19/34
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp150C
Metal TubesB
Requires Quote per FT
2XAO-18
Approx LBS/MFT245.00
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding19/34
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp150C
Metal TubesC
Requires Quote per FT
2XAO-2
Approx LBS/MFT88.00
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding19/34
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp150C
Metal TubesA
Requires Quote per FT
2XAO-40
Approx LBS/MFT100.00
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding19/34
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp150C
Metal TubesG
Requires Quote per FT
2XAO-7
Approx LBS/MFT170.00
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding19/34
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp150C
Metal TubesB
Requires Quote per FT
2XAOW-10
Approx LBS/MFT185.0
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding7/30
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyolefin (XLPO)
Max. Temp105 C
Mil-SpecM24640/6
Requires Quote per FT
2XAOW-18
Approx LBS/MFT263.00
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding7/30
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyolefin (XLPO)
Max. Temp105 C
Mil-SpecM24640/6
Requires Quote per FT
2XAOW-2
Approx LBS/MFT115.10
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding7/30
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyolefin (XLPO)
Max. Temp105 C
Mil-SpecM24640/6
Requires Quote

M24640/6 Shipboard Cable Construction:

  • Conductor: Tinned Copper
  • Insulation: Cross-linked Polyalkene
  • Jacket: Cross-Linked Polyolefin (XLPO)
  • Overall shield
  • Pairs
  • Voltage Rating: 600 volts
