M24640/8 MXO, MXOW

M24640/8 MXO, MXOW Cable

The M24640/8 is a non-flexing, non-watertight shipboard cable. This Mil-Spec cable comes in an alternate variation: MXOW. The MXOW is a watertight, unarmored, and shielded version of the M24640/8 cable. This specialty shipboard cable has a voltage rating of 600 volts and a temperature rating of 150°C.

4 items

MXO-10
Approx LBS/MFT0.00
AWG Size20
Cond. MaterialTinned Copper
Conductor Stranding19/32
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp150C
Metal TubesA
Requires Quote per FT
MXO-14
Approx LBS/MFT0.00
AWG Size20
Cond. MaterialTinned Copper
Conductor Stranding19/32
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialHalogen-Free (LSZH) Cross-Linked Polyolefin (XLPO)
Max. Temp150C
Metal TubesB
Requires Quote per FT
MXOW-10
Approx LBS/MFT119.00
AWG Size20
Cond. MaterialTinned Copper
Conductor Stranding7/28
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyolefin (XLPO)
Max. Temp105 C
Mil-SpecM24640/8
Requires Quote per FT
MXOW-14
Approx LBS/MFT147.00
AWG Size20
Cond. MaterialTinned Copper
Conductor Stranding7/28
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyolefin (XLPO)
Max. Temp105 C
Mil-SpecM24640/8
Requires Quote per FT

M24640/8 MXO, MXOW Shipboard Cable Specifications

M24640/8 Construction:

  • Conductor:Tinned Copper, Multi-conductor
  • Insulation: Cross-Linked Polyalkylene
  • Jacket: LSZH Cross-Linked Polyolefin
  • Shield: Overall Tinned Copper Braid

M24640/8 Ratings and Approvals:

  • Temperature Rating: 150°C
  • Voltage Rating: 600 Volts
  • Mil Spec: M24640/8
  • Navy Spec: MXO
