55A0812-00

55A0812-00
$0.00 /
  • Approx LBS/MFT: 487
  • AWG Size: 00, 2/0
  • Cond. Material: Silver-Coated Copper
  • Conductor Stranding: 1330/30
  • Insul. Material: Cross-Linked Ethylene Tetrafluoroethylene (XL-ETFE)
  • Max. Temp: 200C
  • Mil-Spec: M22759/43
  • Min. Temp: -65C
  • No. of Strands: 1330
  • Nom. Insul. Thick. (in): 0.01, 0.010
  • Nom. O.D. (in): 0.570
  • SAE Spec: AS22759/43
  • Strand Size: 30
  • Voltage: 600

55A0812-00 Cable — Reliable AWG 0 Cable Built to Mil-Spec M22759/43 Standards

Experience exceptional performance with the 55A0812-00 cable, featuring an AWG size of 0 and weighing approximately 487 lbs per thousand feet. Constructed with silver-coated copper conductors and a conductor stranding of 1330/30, this cable ensures reliable conductivity and durability for a wide range of applications.

With Cross-Linked Ethylene Tetrafluoroethylene (XL-ETFE) insulation and a temperature range of up to 200°C, the 55A0812-00 cable is designed to withstand extreme environmental conditions. Compliant with Mil-Spec M22759/43 and SAE Spec AS22759/43 standards, this cable guarantees reliability and consistent performance in demanding applications.

Perfect for aerospace, defense, automotive, and industrial applications, the 55A0812-00 cable is ideal for use in wiring harnesses, power distribution systems, and other critical electrical circuits where high voltage capacity and dependable performance are essential.
