M16878/23BCB 28 Gauge MIL-W-16878/23 Type ET Cable
Our M16878/23BCB cable is part of our Mil-Spec Wire & Cable line of Wire & Cable. M16878/23BCB is composed of a 7/36 stranded nickel-plated copper conductor with polytetrafluoroethylene (PTFE) insulation. These wires are rated for a voltage of 250 volts, have a temperature range of -65° to 260°, and weigh approximately 0.92 lbs/MFT. Per specification, this product will have splices. If continuous lengths are needed, please ask.
M16878/23BCB
Part Number
M16878/23BCB
Attributes
Approx LBS/MFT
0.92
AWG Size
28
Cond. Material
Nickel-Plated Copper
Conductor Stranding
7/36
Insul. Material
Polytetrafluoroethylene (PTFE)
Max O.D. (in)
0.029
Max. Temp
260C
Mil-Spec
M16878/23, MIL-W-16878/23
Min O.D. (in)
0.025
Min. Temp
-65C
NEMA Type
HP3 Type ET
No. of Strands
7
Nom. Dia. of Cond.
0.015
Nom. Insul. Thick. (in)
0.006
Nom. O.D. (in)
0.027
Strand Size
36
Voltage
250
