W-2/0-5C - 2/0 Gauge Multi-Conductor Type W Portable Power Cable
Our W-2/0-5C 2/0 AWG cable is part of our Power Cable and Portable Cord line. The W-2/0-5C cable is composed of 5 stranded bare copper conductors, EPDM insulation, and a black CPE jacket. This cable has a temperature range of -40°C to +90°C and is CSA approved. This flexible cable has excellent impact resistance and can withstand exposure to oil, acid, alkalies, heat, moisture, and most chemicals.
W-2/0-5C
Part Number
W-2/0-5C
Attributes
No. of Cond.
5
Amps
189
Approx LBS/MFT
4180.00
AWG Size
2/0
Color Code
Black, White, Red, Green, Orange
Cond. Material
Bare Copper
Conductor Stranding
259
CSA Type
Approved
Insul. Material
Ethylene Propylene Diene Monomer Rubber (EPDM)
Jacket Material
Chlorinated Polyethylene (CPE)
Max. Temp
90C
Min. Temp
-40C
No. of Strands
259
Nom. Insul. Thick. (in)
0.080
Nom. O.D. of Cable (in)
2.130
UL Style
W
