W-4-5C - 4 Gauge Multi-Conductor Type W Portable Power Cable
Our W-4-5C 4 AWG cable is part of our Power Cable and Portable Cord line. The W-4-5C cable is composed of 5 stranded bare copper conductors, EPDM insulation, and a black CPE jacket. This cable has a temperature range of -40°C to +90°C and is CSA approved. This flexible cable has excellent impact resistance and can withstand exposure to oil, acid, alkalies, heat, moisture, and most chemicals.
W-4-5C
Part Number
W-4-5C
Attributes
No. of Cond.
5
Amps
91
Approx LBS/MFT
1400.00
AWG Size
4
Cond. Material
Bare Copper
Conductor Stranding
259
CSA Type
Approved
Insul. Material
Ethylene Propylene Diene Monomer Rubber (EPDM)
Jacket Material
Chlorosulfonated Polyethylene (CSPE)
Max. Temp
90C
Min. Temp
-40C
No. of Strands
259
Nom. Insul. Thick. (in)
0.060
Nom. O.D. of Cable (in)
1.550
UL Style
W
