UL 4535 Wire is a shielded silicone cable recommended for use in applications where high temperatures, UV light, and mechanical abuse rapidly cause other cables to deteriorate. It is suitable for use in foundries, steel mills, glass factories, baking equipment, burners,  and heating and lighting systems. UL 4535 wire can also be used anywhere saltwater is present and high-temperature processes are utilized. An overall tinned copper shield is recommended whenever electrical interference distorts signal transmission or when EMI emissions need to be suppressed.

139 items

UL 4535 Silicone Cable Specifications

UL 4535 Construction:

  • Conductor: Tinned copper strands
  • Insulation: Besilen® EI2
  • Jacket Material: Besilen® EM9
  • Inner Jack Material: Besilen EM9
  • Jacket Color: Black
  • Color Code: Up to 5 conductors colored from 6 conductors black conductors with consecutive numbers from 3 conductors a green-yellow earth wire
  • Stranding: In layers
  • Screen: Tinned copper braiding

UL 4535 Ratings and Approvals:

  • Minimum Bending Radius:
    • Fixed Installation: 5 x O.D.
    • Free Movement: 10 x O.D.
  • Radiation Resistance: 2 x 107 cJ/kg
  • Temperature Range:
    • DIN VDE:
      • Static: -40ºC/+180ºC
      • Flexing: -25ºC/+180ºC
      • Short-time use: +250ºC
    • UL/CSA:
      • up to +150ºC
  • Burning characteristics: Flame retardant and self-extinguishing
  • Corrosivity: No development of corrosive conflagration gases
  • UL: AWM Style 4535 150°C 600V
  • CSA: AWM I/II A 150°C 600V FT1 FT2
  • CE Approved
  • RoHS Hook-up Wire RoHS Compliant
