44A0114 - M81044/13

The 44A0114 Tyco Raychem Spec 44 wire is a dual layer, lightweight, high-temperature lead wire that is suitable for applications where high-density cabling and harnessing are required. Besides offering size and weight advantages, this lead wire has excellent resistance to cut through, abrasion, cold flow, shrink back, notch propagation, and common chemicals. Additionally, this lead wire strips and stripes easily, may be potted, and has low-smoke characteristics. The 44A0114 aerospace wire is commonly used for airframe, avionics, military vehicle, shipboard, and missile applications.

4 items

44A0114-26
Approx LBS/MFT1.40
AWG Size26
Cond. MaterialSilver-Plated High-Strength Copper Alloy
Conductor Stranding19/38
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/13
Requires Quote per FT
44A0114-24
Approx LBS/MFT2
AWG Size24
Cond. MaterialSilver-Plated High-Strength Copper Alloy
Conductor Stranding19/36
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/13
Requires Quote
44A0114-22
Approx LBS/MFT3
AWG Size22
Cond. MaterialSilver-Plated High-Strength Copper Alloy
Conductor Stranding19/34
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/13
Requires Quote per FT
44A0114-20
Approx LBS/MFT4.5
AWG Size20
Cond. MaterialSilver-Plated High-Strength Copper Alloy
Conductor Stranding19/32
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/13
Requires Quote per FT

44A0114 Tyco Raychem Spec 44 (M81044/13) Specifications

44A0114 Spec 44 Construction:

  • Conductor: Silver-coated high-strength copper alloy
  • Insulation: Radiation-crosslinked, extruded polyalkene
  • Jacket: Radiation-crosslinked, modified PVDF
  • Wall Thickness: 0.1905 mm (0.0075 in.)

44A0114 Raychem Spec 44 Ratings:

  • Min Temperature: - 65°C
  • Max Temperature: 150°C
  • Voltage: 600 Volts

44A0114 Raychem Spec 44 is classified as light weight wire and directly crosses with M81044/13 Mil Spec Wire
