44A0711 - M81044/6

The 44A0711 Tyco Raychem Spec 44 wire is a dual layer, lightweight, high-temperature lead wire that is suitable for applications where high-density cabling and harnessing are required. Besides offering size and weight advantages, this lead wire has excellent resistance to cut through, abrasion, cold flow, shrink back, notch propagation, and common chemicals. Additionally, this lead wire strips and stripes easily, may be potted, and has low-smoke characteristics. The 44A0711 aerospace wire is commonly used for airframe, avionics, military vehicle, shipboard, and missile applications.

14 items

44A0711-26
Approx LBS/MFT3.27
AWG Size26
Cond. MaterialTinned Copper
Conductor Stranding19/38
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote
44A0711-24
Approx LBS/MFT4.46
AWG Size24
Cond. MaterialTinned Copper
Conductor Stranding19/36
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote per FT
44A0711-22
Approx LBS/MFT6.4
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding19/34
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote per FT
44A0711-20
Approx LBS/MFT9.08
AWG Size20
Cond. MaterialTinned Copper
Conductor Stranding19/32
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote per FT
44A0711-18
Approx LBS/MFT12.95
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding19/30
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote per FT
44A0711-16
Approx LBS/MFT16.22
AWG Size16
Cond. MaterialTinned Copper
Conductor Stranding19/29
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote per FT
44A0711-14
Approx LBS/MFT24.11
AWG Size14
Cond. MaterialTinned Copper
Conductor Stranding19/27
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote per FT
44A0711-12
Approx LBS/MFT36.01
AWG Size12
Cond. MaterialTinned Copper
Conductor Stranding37/28
Insul. MaterialCross-Linked Polyalkene
Jacket MaterialCross-Linked Polyvinylidene Fluoride (XL-PVDF)
Max. Temp150C
Mil-SpecM81044/6
Requires Quote

44A0711 Tyco Raychem Spec 44 (M81044/6) Specifications

44A0711 Spec 44 Construction:

  • Conductor: Tin-coated copper
  • Insulation: Radiation-crosslinked, extruded polyalkene
  • Jacket: Radiation-crosslinked, modified PVDF
  • Wall Thickness: 0.508 mm (0.020 in.)

44A0711 Spec 44 Ratings:

  • Min Temperature: - 65°C
  • Max Temperature: 150°C
  • Voltage: 600 Volts

44A0711 Raychem Spec 44 is classified as normal weight, dual wall wire and directly crosses with M81044/6 Mil Spec Wire.
