AWG Size24
Cond. MaterialTinned Copper
Conductor Strandingsolid
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.049
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.041
M16878/10 - Type J
M16878/10 — Type J
The M16878/10 hook-up wire is designed to be used in military harnessing, power supply lead wire, appliance wiring, and medical electronic devices. It is constructed with either a solid or stranded tinned copper conductor and with extruded PE insulation. The M16878/10 has a maximum temperature of 75°C and a voltage rating of 600V.
31 items
AWG Size24
Cond. MaterialTinned Copper
Conductor Stranding7/32
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.053
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.045
AWG Size24
Cond. MaterialTinned Copper
Conductor Stranding19/36
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.053
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.045
AWG Size22
Cond. MaterialTinned Copper
Conductor Strandingsolid
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.055
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.047
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding7/30
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.06, 0.060
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.052
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding19/34
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.06, 0.060
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.052
AWG Size20
Cond. MaterialTinned Copper
Conductor Strandingsolid
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.064
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.056
AWG Size20
Cond. MaterialTinned Copper
Conductor Stranding7/28
Insul. MaterialPolyethylene (PE)
Max O.D. (in)0.07, 0.070
Max. Temp75C
Mil-SpecMIL-W-16878/10
Min O.D. (in)0.062
M16878/10 Mil-Spec Hook-Up Wire Specifications
M16878/10 Wire Construction:
- Conductor: Tinned Copper
- Insulation: Extruded Polyethylene
M16878/10 Ratings and Approvals:
- Max. Temperature: 75°C
- Max. Voltage: 600 volts
- MIL-SPEC: M16878/10
