M16878/20 - Type ET

M16878/20 — Type ET

Our M16878/20 hook-up wire is a durable Mil-Spec wire. It is constructed of a stranded silver-plated copper conductor and PTFE tape insulation. This wire has a temperature range of -65°C to +200°C and a voltage rating of 250V.

8 items

M16878/20BDB
Approx LBS/MFT1.32
AWG Size26
Cond. MaterialSilver-Coated Copper
Conductor Stranding7/34
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.033
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT
M16878/20BDE
Approx LBS/MFT0, 1.34
AWG Size26
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/38
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.033
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT
M16878/20BEB
Approx LBS/MFT0, 1.94
AWG Size24
Cond. MaterialSilver-Coated Copper
Conductor Stranding7/32
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.038
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT
M16878/20BEE
Approx LBS/MFT0, 2
AWG Size24
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.038
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT
M16878/20BFB
Approx LBS/MFT0, 2.84
AWG Size22
Cond. MaterialSilver-Coated Copper
Conductor Stranding7/30
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.044
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT
M16878/20BFE
Approx LBS/MFT0, 3.01
AWG Size22
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/34
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.044
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT
M16878/20BGB
Approx LBS/MFT0, 4.28
AWG Size20
Cond. MaterialSilver-Coated Copper
Conductor Stranding7/28
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.052
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT
M16878/20BGE
Approx LBS/MFT0, 4.56
AWG Size20
Cond. MaterialSilver-Coated Copper
Conductor Stranding19/32
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.052
Max. Temp200C
Mil-SpecM16878/20, MIL-W-16878/20
Requires Quote per FT

M16878/20 Mil-Spec Hook-Up Wire Specifications

M16878/20 Construction:

  • Conductor: Silver Coated Conductor
  • Insulation: 0.006 Wrapped Tape PTFE

M16878/20 Ratings:

  • Temperature Range: -65°C to 200°C
  • Voltage Rating: 250 Volts
