M16878/22 - Type EE

M16878/22 — Type EE

Our M16878/22 hook-up wire is a durable Mil-Spec wire. It is constructed of a stranded silver-plated copper conductor and PTFE tape insulation. This wire has a temperature range of -65°C to +200°C and a voltage rating of 1000V.

16 items

Sort by

Per Page:

M16878/22BDB

Approx LBS/MFT0.00, 2

AWG Size26

Cond. MaterialSilver-Coated Copper

Conductor Stranding7/34

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.053

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22BDE

Approx LBS/MFT0.00, 2

AWG Size26

Cond. MaterialSilver-Coated Copper

Conductor Stranding19/38

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.053

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22BEB

Approx LBS/MFT0.00, 3

AWG Size24

Cond. MaterialSilver-Coated Copper

Conductor Stranding7/32

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.058

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22BEE

Approx LBS/MFT0.00, 3

AWG Size24

Cond. MaterialSilver-Coated Copper

Conductor Stranding19/36

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.088

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22BFB

Approx LBS/MFT0.00, 4

AWG Size22

Cond. MaterialSilver-Coated Copper

Conductor Stranding7/30

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.064

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22BFE

Approx LBS/MFT0.00, 4

AWG Size22

Cond. MaterialSilver-Coated Copper

Conductor Stranding19/34

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.064

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22BGB

Approx LBS/MFT0.00, 6

AWG Size20

Cond. MaterialSilver-Coated Copper

Conductor Stranding7/28

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.072

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22BGE

Approx LBS/MFT0.00, 6

AWG Size20

Cond. MaterialSilver-Coated Copper

Conductor Stranding19/32

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.072

Max. Temp200C

Mil-SpecM16878/22, MIL-W-16878/22

M16878/22 Mil-Spec Hook-Up Wire Specifications

M16878/22 Construction:

Conductor: Silver Coated Copper
Insulation: 0.015 Wrapped Tape PTFE

M16878/22 Ratings:

Temperature Range: -65°C to 200°C
Voltage Rating: 1000 volts

M16878/22 - Type EE

M16878/22 — Type EE
