M16878/25 - Type E

M16878/25 — Type E

Our M16878/25 hook-up wire is a durable Mil-Spec wire. It is constructed of a stranded nickel-plated copper conductor and extruded PTFE insulation. This wire has a temperature range of -65°C to +260°C and a voltage rating of 600V.

19 items

Sort by

Per Page:

M16878/25BAA

Approx LBS/MFT0.00, 1

AWG Size32

Cond. MaterialNickel-Plated Copper

Conductor Stranding7/40

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.034

Max. Temp260C

Mil-SpecM16878/25, MIL-W-16878/25

M16878/25-30-19

Approx LBS/MFT0.00, 1.023

AWG Size30

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/42

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.036

Max. Temp260C

Mil-SpecMIL-W-16878/25

M16878/25BBB

Approx LBS/MFT1, 1.00

AWG Size30

Cond. MaterialNickel-Plated Copper

Conductor Stranding7/38

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.036

Max. Temp260C

Mil-SpecM16878/25, MIL-W-16878/25

M16878/25-28-19

Approx LBS/MFT0.00, 2

AWG Size28

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/40

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.039

Max. Temp260C

Mil-SpecMIL-W-16878/25

M16878/25-28-7

Approx LBS/MFT0.00, 2

AWG Size28

Cond. MaterialNickel-Plated Copper

Conductor Stranding7/36

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.039

Max. Temp260C

Mil-SpecMIL-W-16878/25

M16878/25-26-19

Approx LBS/MFT0.00, 2

AWG Size26

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/38

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.043

Max. Temp260C

Mil-SpecMIL-W-16878/25

M16878/25BDB

Approx LBS/MFT1.73

AWG Size26

Cond. MaterialNickel-Plated Copper

Conductor Stranding7/34

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.043

Max. Temp260C

Mil-SpecM16878/25, MIL-W-16878/25

M16878/25-24-19

Approx LBS/MFT0.00, 3

AWG Size24

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/36

Insul. MaterialPolytetrafluoroethylene (PTFE)

Max O.D. (in)0.048

Max. Temp260C

Mil-SpecMIL-W-16878/25

M16878/25 Mil-Spec Hook-Up Wire Specifications

M16878/25 Construction:

Conductor: Nickel-Coated Copper
Insulation: 0.010 Extruded PTFE

M16878/25 Ratings:

Temperature Range: -65°C to 260°C
Voltage Rating: 600 Volts

*Per specification, this product will have splices. If continuous lengths are needed, please ask.
