M16878/27 - Type EE

M16878/27 — Type EE

Our M16878/27 hook-up wire is a durable Mil-Spec wire. It is constructed of a stranded nickel-plated copper conductor and extruded PTFE insulation. This wire has a temperature range of -65°C to +260°C and a voltage rating of 1000V.

34 items

M16878/27BAB
Approx LBS/MFT1.27
AWG Size32
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/40
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.044
Max. Temp260C
Mil-SpecM16878/27, MIL-W-16878/27
Requires Quote per FT
M16878/27-30-19
Approx LBS/MFT1.56
AWG Size30
Cond. MaterialNickel-Plated Copper
Conductor Stranding19/42
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.046
Max. Temp260C
Mil-SpecMIL-W-16878/27
Requires Quote per FT
M16878/27BBB
Approx LBS/MFT1.54
AWG Size30
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/38
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.046
Max. Temp260C
Mil-SpecM16878/27, MIL-W-16878/27
Requires Quote per FT
M16878/27-28-19
Approx LBS/MFT1.95
AWG Size28
Cond. MaterialNickel-Plated Copper
Conductor Stranding19/40
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.049
Max. Temp260C
Mil-SpecMIL-W-16878/27
Requires Quote per FT
M16878/27BCB
Approx LBS/MFT1.87
AWG Size28
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.049
Max. Temp260C
Mil-SpecM16878/27, MIL-W-16878/27
Requires Quote per FT
M16878/27BDB
Approx LBS/MFT2.37
AWG Size26
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/34
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.053
Max. Temp260C
Mil-SpecM16878/27, MIL-W-16878/27
Requires Quote per FT
M16878/27BDE
Approx LBS/MFT2.49
AWG Size26
Cond. MaterialNickel-Plated Copper
Conductor Stranding19/38
Insul. MaterialPolytetrafluoroethylene (PTFE)
Max O.D. (in)0.053
Max. Temp260C
Mil-SpecM16878/27, MIL-W-16878/27
Requires Quote per FT
M16878/28BDB
Approx LBS/MFT2.37
AWG Size26
Cond. MaterialNickel-Plated Copper
Conductor Stranding7/34
Insul. MaterialWrapped Polytetrafluoroethylene (PTFE) Tape
Max O.D. (in)0.053
Max. Temp260C
Mil-SpecM16878/28, MIL-W-16878/28
Requires Quote per FT

M16878/27 Mil-Spec Hook-Up Wire Specifications

M16878/27 Construction:

  • Conductor: Nickel Coated Conductor
  • Insulation: Extruded PTFE, .015" Nominal Wall Thickness

M16878/27 Ratings and Approvals:

  • Temperature Range: -65°C to 260°C
  • Voltage Rating: 1000 volts
  • Mil Spec: Mil-DTL-16878G
  • Nema: NEMA HP3

*Per specification, this product will have splices. If continuous lengths are needed, please ask.
