Approx LBS/MFT2.4
AWG Size24
Cond. MaterialTinned Copper
Conductor Stranding7/32
Insul. MaterialSilicone Rubber
Max O.D. (in)0.058
Max. Temp150C
Mil-SpecM16878/29, MIL-W-16878/29
M16878/29 - Type F
M16878/29 — Type F
Our M16878/29 hook-up wire is a durable Mil-Spec wire. It is constructed of a stranded tinned copper conductor and extruded silicone rubber insulation. This wire has a maximum temperature of +150°C and a voltage rating of 600V. M16878/29 wire may be used as exposed leads.
7 items
Approx LBS/MFT3.7
AWG Size22
Cond. MaterialTinned Copper
Conductor Stranding7/30
Insul. MaterialSilicone Rubber
Max O.D. (in)0.064
Max. Temp150C
Mil-SpecM16878/29, MIL-W-16878/29
Approx LBS/MFT5
AWG Size20
Cond. MaterialTinned Copper
Conductor Stranding7/28
Insul. MaterialSilicone Rubber
Max O.D. (in)0.072
Max. Temp150C
Mil-SpecM16878/29, MIL-W-16878/29
Approx LBS/MFT7.1
AWG Size18
Cond. MaterialTinned Copper
Conductor Stranding7/26
Insul. MaterialSilicone Rubber
Max O.D. (in)0.082
Max. Temp150C
Mil-SpecM16878/29, MIL-W-16878/29
Approx LBS/MFT9.3
AWG Size16
Cond. MaterialTinned Copper
Conductor Stranding19/29
Insul. MaterialSilicone Rubber
Max O.D. (in)0.091
Max. Temp150C
Mil-SpecM16878/29, MIL-W-16878/29
Approx LBS/MFT15.6
AWG Size14
Cond. MaterialTinned Copper
Conductor Stranding19/27
Insul. MaterialSilicone Rubber
Max O.D. (in)0.122
Max. Temp150C
Mil-SpecM16878/29, MIL-W-16878/29
Approx LBS/MFT23.2
AWG Size12
Cond. MaterialTinned Copper
Conductor Stranding19/25
Insul. MaterialSilicone Rubber
Max O.D. (in)0.141
Max. Temp150C
Mil-SpecM16878/29, MIL-W-16878/29
M16878/29 Mil-Spec Hook-Up Wire Specifications
M16878/29 Construction:
- Conductor: Stranded Tinned Copper, Color Coded
- Insulation: Extruded Silicone Rubber
M16878/29 Ratings:
- Temperature Range: 150°C
- Voltage Rating: 600 volts
