M16878/36 - Type LS

M16878/36 — Type LS

Our M16878/36 hook-up wire is a durable Mil-Spec wire. It is constructed of either a stranded or solid tinned copper conductor and extruded, low-smoke XLPO insulation. This wire has a maximum temperature of +105°C and a voltage rating of 600V.

26 items

M16878/36BAA
AWG Size32
Cond. MaterialTinned Copper
Conductor Strandingsolid
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.03, 0.030
Max. Temp105C
Mil-SpecMIL-W-16878/36
Min O.D. (in)0.024
Requires Quote per FT
M16878/36BAB
AWG Size32
Cond. MaterialTinned Copper
Conductor Stranding7/40
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.032
Max. Temp105C
Mil-SpecMIL-W-16878/36
Min O.D. (in)0.026
Requires Quote per FT
M16878/36BBA
AWG Size30
Cond. MaterialTinned Copper
Conductor Strandingsolid
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.032
Max. Temp105C
Mil-SpecMIL-W-16878/36
Min O.D. (in)0.026
Requires Quote per FT
M16878/36BBB
AWG Size30
Cond. MaterialTinned Copper
Conductor Stranding7/38
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.034
Max. Temp105C
Mil-SpecMIL-W-16878/36
Min O.D. (in)0.026
Requires Quote per FT
M16878/36BCA
AWG Size28
Cond. MaterialTinned Copper
Conductor Strandingsolid
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.035
Max. Temp105C
Mil-SpecMIL-W-16878/36
Min O.D. (in)0.028
Requires Quote per FT
M16878/36BCB
AWG Size28
Cond. MaterialTinned Copper
Conductor Stranding7/36
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.037
Max. Temp105C
Mil-SpecMIL-W-16878/36
Min O.D. (in)0.029
Requires Quote per FT
M16878/36BDA
AWG Size26
Cond. MaterialTinned Copper
Conductor Strandingsolid
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.038
Max. Temp105C
Mil-SpecMIL-W-16878/36
Min O.D. (in)0.031
Requires Quote per FT
M16878/36BDB
Approx LBS/MFT2
AWG Size26
Cond. MaterialTinned Copper
Conductor Stranding7/34
Insul. MaterialCross-Linked Polyolefin (XLPO)
Max O.D. (in)0.041
Max. Temp105C
Mil-SpecMIL-W-16878/36
Requires Quote per FT

M16878/36 Mil-Spec Hook-Up Wire Specifications

M16878/36 Construction:

  • Conductor: Tinned Copper (Part #M16878/36DGA has a Silver-Coated High Strength Copper Alloy Conductor)
  • Insulation: Extruded Low Smoke Cross-Linked Polyolefin (XLPO)

M16878/36 Ratings and Approvals:

  • Mil Spec: MIL-W-16878/36
  • Max. Temperature: 105°C
  • Max. Voltage: 600 volts
