M915/66 MSPW

M915/66 (MSPW) Cable

The M915/66 cable is a multi-conductor shipboard cable suitable for watertight and non-flexing service. This Mil-Spec cable is constructed of tinned copper conductors, fluoropolymer insulation, and a polyamide/polyester tape jacket. It also features an overall braided tinned copper shield. This cable is suitable for use in naval circuit applications and has a voltage rating of 600V.

1 item

MSPW
Approx LBS/MFT0.00
Composite Construction(16) 22 AWG Conductors, (18) 20 AWG Conductors and (25) 16 AWG Conductors
Cond. MaterialTinned Copper
Insul. MaterialFluoropolymer
Jacket MaterialPolyamide/Polyester Tape
Max O.D. (in)1.635
Metal TubesR
Mil-SpecM915E/66
Requires Quote per FT

M915/66 (MSPW) Shipboard Cable Specifications

M915/66 Construction:

  • Conductor: Tinned Copper
  • Insulation: Fluoropolymer
  • Jacket: Polyamide/Polyester Tape
  • Shield: Overall Tinned Copper Braid Shield
  • Combination construction
  • Unarmored with surface marking

M915/66 Approvals and Ratings:

  • Mil-Spec: MIL-C-915E
  • Navy Spec: MSPW
  • Voltage Rating: 600 Volts
