M22759/15

M22759/15 Wire

Our M22759/15 wire is a highly durable Mil-Spec wire designed to be used in aircraft applications. This wire is constructed of silver-coated, high-strength copper alloy conductors, extruded FEP insulation, and a clear PVDF jacket. It also has a maximum temperature of +135°C and a voltage rating of 600V.

4 items

m22759/15-26
M22759/15-26
Approx LBS/MFT1.75
AWG Size26
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/38
Insul. MaterialFluorinated Ethylene Propylene (FEP)
Jacket MaterialPolyvinylidene Fluoride (PVDF)
M27500 ComponentCC
Max O.D. (in)0.039
Requires Quote per FT
m22759/15-24
M22759/15-24
Approx LBS/MFT2.42
AWG Size24
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/36
Insul. MaterialFluorinated Ethylene Propylene (FEP)
Jacket MaterialPolyvinylidene Fluoride (PVDF)
M27500 ComponentCC
Max O.D. (in)0.044
Requires Quote per FT
m22759/15-22
M22759/15-22
Approx LBS/MFT3.59
AWG Size22
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/34
Insul. MaterialFluorinated Ethylene Propylene (FEP)
Jacket MaterialPolyvinylidene Fluoride (PVDF)
M27500 ComponentCC
Max O.D. (in)0.051
Requires Quote per FT
m22759/15-20
M22759/15-20
Approx LBS/MFT5.22
AWG Size20
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/32
Insul. MaterialFluorinated Ethylene Propylene (FEP)
Jacket MaterialPolyvinylidene Fluoride (PVDF)
M27500 ComponentCC
Max O.D. (in)0.059
Requires Quote per FT

M22759/15 Mil-Spec Wire Specifications

M22759/15 Construction:

  • Conductor: Silver-Coated, High-Strength Copper Alloys
  • Insulation: Extruded FEP
  • Jacket: Clear PVDF

M22759/15 Ratings and Approvals:

  • Voltage Rating: 600 Volts
  • Temperature Rating: 135°C
  • SAE: AS22759/15
