M22759/2

M22759/2 Wire

Our M22759/2 wire is a highly durable Mil-Spec wire designed to be used in aircraft and military applications where abrasion is a concern. This wire is constructed of nickel-plated copper conductors, PTFE insulation, a PTFE jacket, and and impregnated braided PTFE coated fiberglass shield. It is lightweight and has low flame propagation. This wire also has a maximum temperature of +260°C and a voltage rating of 600V.

16 items

Sort by

Per Page:

M22759/2-22

Approx LBS/MFT7.5, 7.50

AWG Size22

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/34

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.088

M22759/2-20

Approx LBS/MFT9.5, 9.50

AWG Size20

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/32

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.098

M22759/2-18

Approx LBS/MFT13, 13.00

AWG Size18

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/30

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.11, 0.110

M22759/2-16

Approx LBS/MFT16.5, 16.50

AWG Size16

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/29

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.125

M22759/2-14

Approx LBS/MFT23, 23.00

AWG Size14

Cond. MaterialNickel-Plated Copper

Conductor Stranding19/27

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.143

M22759/2-12

Approx LBS/MFT32.1, 32.10

AWG Size12

Cond. MaterialNickel-Plated Copper

Conductor Stranding37/28

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.162

M22759/2-10

Approx LBS/MFT47, 47.00

AWG Size10

Cond. MaterialNickel-Plated Copper

Conductor Stranding37/26

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.188

M22759/2-8

Approx LBS/MFT82, 82.00

AWG Size8

Cond. MaterialNickel-Plated Copper

Conductor Stranding133/29

Insul. MaterialPolytetrafluoroethylene (PTFE)

Jacket MaterialPolytetrafluoroethylene (PTFE)

M27500 ComponentE

Max O.D. (in)0.255

M22759/2

M22759/2 Wire

16 items
