M22759/20

M22759/20 Wire

Our M22759/20 wire is a highly durable Mil-Spec wire designed to be used in aircraft and military applications where abrasion is a concern. This wire is constructed of silver-coated, high-strength copper alloy conductors and extruded PTFE insulation. This wire also has a maximum temperature of +200°C and a voltage rating of 1000V.

5 items

m22759/20-28
M22759/20-28
Approx LBS/MFT1.91
AWG Size28
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding7/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTK
Max O.D. (in)0.045
Requires Quote per FT
m22759/20-26
M22759/20-26
Approx LBS/MFT2.57
AWG Size26
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/38
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTK
Max O.D. (in)0.05, 0.050
Requires Quote per FT
m22759/20-24
M22759/20-24
Approx LBS/MFT3.35
AWG Size24
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTK
Max O.D. (in)0.055
Requires Quote per FT
m22759/20-22
M22759/20-22
Approx LBS/MFT4.59
AWG Size22
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/34
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTK
Max O.D. (in)0.062
Requires Quote per FT
m22759/20-20
M22759/20-20
Approx LBS/MFT6.41
AWG Size20
Cond. MaterialSilver Plated Copper, Silver-Coated Copper Alloy (High Strength)
Conductor Stranding19/32
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTK
Max O.D. (in)0.07, 0.070
Requires Quote per FT

M22759/20 Mil-Spec Wire Specifications

M22759/20 Construction:

  • Conductor: Silver-coated high strength copper alloy
  • Insulation: Extruded PTFE

M22759/20 Ratings and Approvals:

  • Voltage Rating: 1000 Volts
  • Temperature Rating: 200°C
  • SAE: AS22759/20

*Per specification, this product will have splices. If continuous lengths are needed, please ask.
