M22759/21

M22759/21 Wire

Our M22759/21 wire is a highly durable Mil-Spec wire designed to be used in aircraft and military applications where abrasion is a concern. This wire is constructed of silver-coated, high-strength copper alloy conductors and extruded PTFE insulation. This wire also has a maximum temperature of +260°C and a voltage rating of 1000V.

5 items

m22759/21-28
M22759/21-28
Approx LBS/MFT1.93
AWG Size28
Cond. MaterialNickel Plated Copper Alloy (High Strength), Nickel-Plated Copper Alloy (High Strength)
Conductor Stranding7/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTL
Max O.D. (in)0.045
Requires Quote per FT
m22759/21-26
M22759/21-26
Approx LBS/MFT2.6, 2.60
AWG Size26
Cond. MaterialNickel Plated Copper Alloy (High Strength), Nickel-Plated Copper Alloy (High Strength)
Conductor Stranding19/38
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTL
Max O.D. (in)0.05, 0.050
Requires Quote per FT
m22759/21-24
M22759/21-24
Approx LBS/MFT3.38
AWG Size24
Cond. MaterialNickel Plated Copper Alloy (High Strength), Nickel-Plated Copper Alloy (High Strength)
Conductor Stranding19/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTL
Max O.D. (in)0.055
Requires Quote per FT
m22759/21-22
M22759/21-22
Approx LBS/MFT4.61
AWG Size22
Cond. MaterialNickel Plated Copper Alloy (High Strength), Nickel-Plated Copper Alloy (High Strength)
Conductor Stranding19/34
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTL
Max O.D. (in)0.062
Requires Quote per FT
m22759/21-20
M22759/21-20
Approx LBS/MFT6.43
AWG Size20
Cond. MaterialNickel Plated Copper Alloy (High Strength), Nickel-Plated Copper Alloy (High Strength)
Conductor Stranding19/32
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTL
Max O.D. (in)0.07, 0.070
Requires Quote per FT

M22759/21 Mil-Spec Wire Specifications

M22759/21 Construction:

  • Conductor: Silver-coated high strength copper alloy
  • Insulation: Extruded PTFE

M22759/21 Ratings and Approvals:

  • Voltage Rating: 1000 Volts
  • Temperature Rating: 260°C
  • SAE: AS22759/21

*Per specification, this product will have splices. If continuous lengths are needed, please ask.
