Approx LBS/MFT0, 0.00
AWG Size28
Cond. MaterialSilver-Coated Copper Alloy (High Strength)
Conductor Stranding7/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTM
Max O.D. (in)0.035
M22759/22
M22759/22 Wire
Our M22759/22 wire is a highly durable Mil-Spec wire designed to be used as hook-up wire in applications where high temperatures, smoke emissions, and flammability are a concern. This wire is constructed of silver-coated, high-strength copper alloy conductors and extruded PTFE insulation. This wire also has a maximum temperature of +200°C and a voltage rating of 600V.
5 items
Approx LBS/MFT0, 0.00
AWG Size26
Cond. MaterialSilver-Coated Copper Alloy (High Strength)
Conductor Stranding19/38
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTM
Max O.D. (in)0.04, 0.040
Approx LBS/MFT2.61
AWG Size24
Cond. MaterialSilver-Coated Copper Alloy (High Strength)
Conductor Stranding19/36
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTM
Max O.D. (in)0.045
Approx LBS/MFT0, 0.00
AWG Size22
Cond. MaterialSilver-Coated Copper Alloy (High Strength)
Conductor Stranding19/34
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTM
Max O.D. (in)0.051
Approx LBS/MFT0, 0.00
AWG Size20
Cond. MaterialSilver-Coated Copper Alloy (High Strength)
Conductor Stranding19/32
Insul. MaterialPolytetrafluoroethylene (PTFE)
Jacket MaterialPolytetrafluoroethylene (PTFE)
M27500 ComponentTM
Max O.D. (in)0.06, 0.060
